Working in close collaboration with our team, Czech TV was supported by a systems integrator with over 20 years experience in designing and delivering quality broadcast solutions. Omneon servers are configured for main and backup playout for all master control rooms.

TV MCR CH TIMETAG ARCHIVE

Content is recorded to Teracue‘s DVB- ASI module and ICUE streaming server, which ensure storage of the whole DVB-T packet including EPG, PID tables and individual channels to the archive server for a period of 1 month. Each room is equipped with two modules with three 40“ LCD multiscreens displaying up to 24 signals, from both the input and output matrix and backup outgoing routes. Video signals are monitored by Evertz multiviewers. Harris Platinum matrixes are used to enable SDI, HD-SDI, AES-EBU and analog inputs and outputs up to 512×512 configuration (output matrix up to 256×256). Input processing consists of four SDI frame-synchronizers with Harris SDI distribution amplifiers. Master control rooms are equipped with Harris IconMaster master control systems – consisting of independent mix/effect unit, external matrix and control panels. The Aveco Astra automated control system sits at the centre of the whole solution.

Providing leading design, systems integration of legacy and new technology, project management and technical support, our team delivered this complex project, the first of its kind in the Czech Republic, on time and within expected budget.

A highly redundant and universal master control room system applying the N+1 principle, easily extendable to other distribution channels in the future. Technical solution was designed for maximum flexibility and includes following main principles.

Configurable monitoring of all signals on multiscreens The broadcaster needed to be able to control any TV channel to any output, from any MCR suite.

Fully flexible configuration enabling easy grouping of MCRs and switching of control between them.

A highly redundant and universal master control room system applying the N+1 principle, easily extendable to other distribution channels in the future.The broadcaster needed to be able to control any TV channel to any output, from any MCR suite. In addition, Czech TV demanded total interoperability and inter-changeability. The aim was to enable transmission of its four terrestrial television channels across multiple distribution networks.Īs with any MCR and playout system absolute reliability was essential. In a major initiative to improve and expand its playout operation, Czech TV sought to implement a new master control room (MCR). Committed to the delivery of a premium viewing experience for its audience, Czech TV deploys the latest technology to optimize its operations, making it one of the most respected and successful broadcasters in the region. From family-oriented programming through to news and sports, the Czech Republic’s public broadcaster Czech TV provides a broad range of information and entertainment for all.
